A5

Illustration
Illustration
Illustration
Application

General lighting, recessed or surface mounted

Application domains

  • It is designed for general lighting applications for offices, hospitals, schools, restaurants, shops, stores, etc.

Advantages

  • Customizable in size and power

  • Surface-mounted, suspended or recessed installation

  • 11 mm thickness

  • Very light

  • Light guide plate and PMMA diffuser (no yellowing over time)

Specifications

  • Power W

    18W / 30W / 36W / 48W / 60W

  • Temperature °K

    3000°K / 4000°K / 6000°K

  • Lumens Lm

    2160 lm / 3600 lm /4320 lm / 5760 lm / 7200 lm

  • Efficiency Lm/W

    110 lm/W / 120 lm/W

  • Angle °

    110°

  • Dimensions cm

    30 x 30 cm / 30 x 60 cm / 30 x 120 cm / 60 x 60 cm / 60 x 90 cm / 60 x 120 cm Dimensions personnalisable

  • General Characteristics

    • Long life of 60,000 hours

    • Efficiency up to 120lm/w

    • Customizable nominal power

    • LED edge lighting panel

    • Dimensions 600*600 or 300*1200

    • Frosted PS/PC diffuser UGR<22 Prismatic diffuser UGR<19

    • 650°/850° incandescent wire test

    • Uniform lighting and soft light

    • ON-OFF, 0-10V push-button dimming

    • Suspended/surface/recessed

    Available Versions

    • 0-10V

    • 3CCT

    • CRI>90

    • Dali

    • Emergency

    • Customizable powers

    • UGR<19

    • Up&Down
