FZMP SCG - Glass Fiber

Application

Filtration for air treatment plants equipped with a pre-filter upstream, and in air conditioning cabinets.

Application areas

  • Compact and economical
  • Large filtration surface area
  • High efficiency
  • Tested for food contact according to CE 1935/2004
  • Certified inert to microbial growth (ISO 846-VDI 6022)
Certificates

General Characteristics

Filtration class ISO 16890 : 2016
Media: mini-pleated fiberglass paper
Frame: galvanised (G), plastic (PL), FiberPlast (F1-F2-F3-F4), Cardboard (CA)
Separators: hot-melt
Final pressure drop according to EN 13053: initial pressure drop + 100 Pa or initial pressure drop x3 (whichever is smaller).
Recommended ECO final pressure drop: 250 Pa
Maximum continuous service temperature: 70°C
Relative humidity: 100%
Contact our expert

  • FZMP SCG - Glass Fiber

    Illustration variation

  • ePM10 70% ISO 16890 - (M6)

    • FZMP 65 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      47

    • Surface (m2)

      6

    • Airflow (m3/h)/Delta P (Pa)

      2000 / 42

    • Energy consumption (kWh/year)*

      >1300

    • Energy class**

      E

    • FZMP 65 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      47

    • Surface (m2)

      5

    • Airflow (m3/h)/Delta P (Pa)

      1700 / 42

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 65 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      47

    • Surface (m2)

      3

    • Airflow (m3/h)/Delta P (Pa)

      1000 / 42

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 65 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      97

    • Surface (m2)

      11

    • Airflow (m3/h)/Delta P (Pa)

      2880 / 81

    • Energy consumption (kWh/year)*

      >1300

    • Energy class**

      E

    • FZMP 65 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      97

    • Surface (m2)

      9

    • Airflow (m3/h)/Delta P (Pa)

      2390 / 81

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 65 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      97

    • Surface (m2)

      5,5

    • Airflow (m3/h)/Delta P (Pa)

      1440 / 81

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

  • ePM1 60% ISO 16890 - (F7)

    • FZMP 85 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      47

    • Surface (m2)

      6

    • Airflow (m3/h)/Delta P (Pa)

      2000 / 69

    • Energy consumption (kWh/year)*

      >2050

    • Energy class**

      E

    • FZMP 85 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      47

    • Surface (m2)

      5

    • Airflow (m3/h)/Delta P (Pa)

      1700 / 69

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 85 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      47

    • Surface (m2)

      3

    • Airflow (m3/h)/Delta P (Pa)

      1000 / 69

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 85 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      97

    • Surface (m2)

      11

    • Airflow (m3/h)/Delta P (Pa)

      2880 / 90

    • Energy consumption (kWh/year)*

      >2050

    • Energy class**

      E

    • FZMP 85 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      97

    • Surface (m2)

      9

    • Airflow (m3/h)/Delta P (Pa)

      2390 / 90

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 85 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      97

    • Surface (m2)

      5,5

    • Airflow (m3/h)/Delta P (Pa)

      1440 / 90

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

  • ePM1 70% ISO16890 - (F8)

    • FZMP 95 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      47

    • Surface (m2)

      6

    • Airflow (m3/h)/Delta P (Pa)

      2000 / 96

    • Energy consumption (kWh/year)*

      >2150

    • Energy class**

      E

    • FZMP 95 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      47

    • Surface (m2)

      5

    • Airflow (m3/h)/Delta P (Pa)

      1700 / 96

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 95 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      47

    • Surface (m2)

      3

    • Airflow (m3/h)/Delta P (Pa)

      1000 / 96

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 95 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      97

    • Surface (m2)

      11

    • Airflow (m3/h)/Delta P (Pa)

      2880 / 100

    • Energy consumption (kWh/year)*

      >2150

    • Energy class**

      E

    • FZMP 95 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      97

    • Surface (m2)

      9

    • Airflow (m3/h)/Delta P (Pa)

      2390 / 100

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 95 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      97

    • Surface (m2)

      5,5

    • Airflow (m3/h)/Delta P (Pa)

      1440 / 100

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

  • ePM1 80% ISO16890 - (F9)

    • FZMP 98 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      47

    • Surface (m2)

      6

    • Airflow (m3/h)/Delta P (Pa)

      2000 / 145

    • Energy consumption (kWh/year)*

      >2400

    • Energy class**

      E

    • FZMP 98 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      47

    • Surface (m2)

      5

    • Airflow (m3/h)/Delta P (Pa)

      1700 / 145

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 98 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      47

    • Surface (m2)

      3

    • Airflow (m3/h)/Delta P (Pa)

      1000 / 145

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 98 SCG

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Thickness C (mm)

      97

    • Surface (m2)

      11

    • Airflow (m3/h)/Delta P (Pa)

      2880 / 130

    • Energy consumption (kWh/year)*

      >2400

    • Energy class**

      E

    • FZMP 98 SCG

    • Base A (mm)

      592

    • Height B (mm)

      490

    • Thickness C (mm)

      97

    • Surface (m2)

      9

    • Airflow (m3/h)/Delta P (Pa)

      2390 / 130

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -

    • FZMP 98 SCG

    • Base A (mm)

      592

    • Height B (mm)

      287

    • Thickness C (mm)

      97

    • Surface (m2)

      5,5

    • Airflow (m3/h)/Delta P (Pa)

      1440 / 130

    • Energy consumption (kWh/year)*

      -

    • Energy class**

      -
