Need help?

DG

Illustration
Illustration
Application

Pre-filtration for general ventilation and air conditioning systems

Application areas

Pre-filtration for gas turbines

  • Deltrian cutting service
  • Increasing density
  • Multiple efficiencies
  • Range of impregnated media ‘Oiled series’
  • High retention power
  • Filtration direction indicated by yellow/white coloring
Certificates

General Characteristics

Media: impregnated glass fibers
Green color on the dirty air side
Final pressure drop according to EN 13053: initial pressure drop + 50 Pa or initial pressure drop x3 (whichever is smaller).
Maximum continuous service temperature: 120 °C
Relative Humidity: 100%
Contact our expert

  • DG

    Illustration variation

  • ISO COARSE 50% ISO 16890 - (G3)

    • DG 1"

    • Base A (mm)

      2000

    • Length B (m)

      20

    • Thickness C (mm)

      25

    • Surface (m2)

      40

    • Airflow (m3/h/m2)/Delta P (Pa)

      5400 / 25

    • DG 2"

    • Base A (mm)

      2000

    • Length B (m)

      20

    • Thickness C (mm)

      50

    • Surface (m2)

      40

    • Airflow (m3/h/m2)/Delta P (Pa)

      5400 / 35

    • DG 4"

    • Base A (mm)

      2000

    • Length B (m)

      20

    • Thickness C (mm)

      100

    • Surface (m2)

      40

    • Airflow (m3/h/m2)/Delta P (Pa)

      9000 / 75

  • ISO COARSE 60% ISO 16890 - (G4)

    • DGGT 4" *

    • Base A (mm)

      2000

    • Length B (m)

      20

    • Thickness C (mm)

      100

    • Surface (m2)

      40

    • Airflow (m3/h/m2)/Delta P (Pa)

      9720 / 90

  • ISO COARSE 50% ISO 16890 - (G3)

    • DGMC 3"

    • Base A (mm)

      1000

    • Length B (m)

      20

    • Thickness C (mm)

      75

    • Surface (m2)

      20

    • Airflow (m3/h/m2)/Delta P (Pa)

      9000 / 45

  • ISO COARSE 50% ISO 16890 - (G3)

    • DGPS 2,5"

    • Base A (mm)

      2000

    • Length B (m)

      20

    • Thickness C (mm)

      65

    • Surface (m2)

      40

    • Airflow (m3/h/m2)/Delta P (Pa)

      6300 / 32

    • DGPS 4"

    • Base A (mm)

      2000

    • Length B (m)

      20

    • Thickness C (mm)

      100

    • Surface (m2)

      40

    • Airflow (m3/h/m2)/Delta P (Pa)

      6300 / 40
