M6

Illustration
Illustration
Illustration
Application

Final filters in general ventilation and air conditioning systems in offices, shopping centers, theaters, hotels, industrial sites, the food industry, laboratories, etc.

Application areas

Prefilter for paint booth air intakes, electrical rooms, and in front of any fine or absolute filter

  • Economical
  • Low pressure drop
  • Self-supporting conical pockets (100% synthetic)
  • High retention capacity
  • Very good mechanical resistance
  • 100% incinerable
Certificates

General Characteristics

  • Filtration class according to ISO16890: 2016

  • Frame: thermo-molded plastic

  • Media: synthetic

  • Final pressure drop: 450 Pa

  • Maximum continuous service temperature: 70°C

  • Relative humidity: 100% RH

Contact our expert

  • M6

    Illustration variation

  • ePM10 55% ISO16890 - (M6)

    • PTL65-6/600/8

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Depth C (mm)

      600

    • Pockets

      8

    • Surface (m2)

      5,9

    • Airflow (m3/h)/Delta P (Pa)

      3400 / 54

    • Energy consumption (kWh/year)*

      627

    • PTL65-5/600/6

    • Base A (mm)

      490

    • Height B (mm)

      592

    • Depth C (mm)

      600

    • Pockets

      6

    • Surface (m2)

      4,4

    • Airflow (m3/h)/Delta P (Pa)

      2800 / 54

    • Energy consumption (kWh/year)*

    • PTL65-3/600/4

    • Base A (mm)

      287

    • Height B (mm)

      592

    • Depth C (mm)

      600

    • Pockets

      4

    • Surface (m2)

      2,9

    • Airflow (m3/h)/Delta P (Pa)

      1700 / 54

    • Energy consumption (kWh/year)*

  • ePM10 60% ISO16890 - (M6)

    • PTL65-6/600/8

    • Base A (mm)

      592

    • Height B (mm)

      592

    • Depth C (mm)

      600

    • Pockets

      8

    • Surface (m2)

      5,9

    • Airflow (m3/h)/Delta P (Pa)

      4250 / 75

    • Energy consumption (kWh/year)*

    • PTL65-5/600/6

    • Base A (mm)

      490

    • Height B (mm)

      592

    • Depth C (mm)

      600

    • Pockets

      6

    • Surface (m2)

      4,4

    • Airflow (m3/h)/Delta P (Pa)

      3400 / 75

    • Energy consumption (kWh/year)*

    • PTL65-3/600/4

    • Base A (mm)

      287

    • Height B (mm)

      592

    • Depth C (mm)

      600

    • Pockets

      4

    • Surface (m2)

      2,9

    • Airflow (m3/h)/Delta P (Pa)

      2125 / 75

    • Energy consumption (kWh/year)*

* Energy consumption, kWh/year: calculated according to Eurovent Guideline 4/21-2018 | ** Energy class: according to Eurovent RS4/C/001-2019 | *** Energy class: according to Eurovent RS4/C/001-2015
